Premium ASTM-standard honed hydraulic cylinder tubes with high precision internal finish, tight tolerances (H8/H9), seamless cold-drawn construction, and durable performance for heavy duty hydraulic systems.
Product Description
Our ASTM Standard Precision Honed Hydraulic Cylinder Tube is designed for high-performance hydraulic and pneumatic cylinder applications where accuracy, durability and reliability are critical. Manufactured from high-quality seamless cold-drawn steel and finished by precision honing or skiving & roller burnishing, the tube provides an ultra-smooth bore surface and tight dimensional control to ensure efficient piston movement and long service life.
The internal surface finish achieves excellent roughness levels, reducing friction, improving sealing performance and minimizing wear of seals and piston components. With controlled straightness and consistent wall thickness, our honed tubes are ideal for demanding working conditions in hydraulic systems.
Produced in accordance with international standards such as ASTM A519 / A513, DIN 2391 and EN 10305-1, our hydraulic cylinder tubes are available in both metric and imperial sizes. Internal diameter tolerances can reach H8 / H9, with surface roughness as low as Ra 0.2–0.4 μm, meeting the requirements of high-precision hydraulic cylinder manufacturing.
These tubes are widely used in construction machinery, agricultural equipment, material handling systems, industrial automation, lifting equipment and heavy-duty hydraulic systems, where reliable sealing, low friction and stable performance are essential.
Custom sizes, lengths, tolerances and machining services are available to match specific application requirements.
Technical Specifications
| Item | Specification |
|---|---|
| Product Type | Honed Tube / Hydraulic Cylinder Tube |
| Manufacturing Process | Seamless cold-drawn, honed or skiving & roller burnished |
| Standards | ASTM A519 / ASTM A513 / DIN 2391 / EN 10305-1 |
| Material Grades | E355 / ST52, SAE 1020 / 1026, 20MnV6, optional stainless steel |
| Inner Diameter Tolerance | H8 / H9 (custom available) |
| Surface Roughness | Ra 0.2–0.4 μm |
| Outer Diameter | Customizable |
| Wall Thickness | Customizable |
| Length | Random or fixed length as required |
| Straightness | High straightness, suitable for cylinder machining |
| Application | Hydraulic & pneumatic cylinders |
Key Advantages
Ultra-smooth honed bore for reduced friction and improved sealing
Tight tolerance (H8/H9) for precision hydraulic cylinder manufacturing
Seamless structure ensures high pressure resistance and long service life
Stable mechanical performance under heavy-duty working conditions
Full customization available for diameter, length, tolerance and material
Applications
Hydraulic cylinders for construction machinery
Agricultural and forestry equipment
Material handling and lifting systems
Industrial automation and hydraulic power units
Engineering machinery and heavy equipment
Customization & Supply
We provide custom machining, cutting, tolerance control and material selection according to customer drawings or technical requirements. OEM and bulk orders are supported with stable quality control and export packaging.
